Hub Switch

Omada ES220GMP, 16 Port Gigabit, 16 Port PoE+, 2 Port Gigabit SFP, 250W, Yönetilebilir, Rackmount Switch

Omada

Renk 20 Adet

Ürün Tipi NETWORK GRUBU

KDV Oranı %20

Stokta var (10 adet)

₺6.212,77 (KDV Hariç)

KDV Dahil: ₺7.455,32

KDV Tutarı (%20): ₺1.242,55

Adet

Ürün Kodu: #294

KDV Oranı: %20

ERP Kodu: ES220GMP

Durum: Aktif

PoE Port: 16 Adet

Rack Kabin: Uyumlu

RJ45 Port: 20 Adet

RJ45 Veri Hızı: 1Gbps

SFP Port: 2 Adet

Yönetilebilir: Yönetilebilir

DONANIM ZELLİKLERİ
Arabirim	• 16× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+) • 2× 10/100/1000 Mbps RJ45 Port • 2× Gigabit SFP Slot • Auto-Negotiation/Auto MDI/MDIX
Fan Sayısı	2
Kurulum	Rackmountable
Fiziksel Gvenlik Kilidi	√
G Kaynağı	100–240V AC, 50/60Hz
PoE Portları (RJ45)	• Standard: 802.3af PoE and 802.3at PoE+ compliant • PoE Ports: 16 ports • PoE Budget: 250W available for all PoE+ ports, 30W max per port • Fast PoE & Perpetual PoE • PoE Auto Recovery^‡ • Up to 250m PoE transmission distance**
Boyutlar ( W X D X H )	17.3 × 7.1 × 1.7 in.(440 × 180 × 44 mm)
Surge Protection	±6kV

YAZILIM ZELLİKLERİ
Quality of Service	• Port-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control^△
L2 zellikleri	• Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDP
L2 Multicast	• IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave
VLAN	• MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID
İletim Metodu	Store-And-Forward

YNETİM
Omada App	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller
Cloud Access	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning	Yes. Requires the use of Omada Cloud-Based Controller
Management Features	• Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery^† • Batch Configuration^† • Batch Firmware Upgrading^† • Unified Configuration^†

DİĞERLERİ
Sertifika	FCC, CE, RoHS
Paket İeriği	• ES220GMP • Power Cord • Mounting Brackets • Rubber Feet • Screws • Installation Guide
Ortam	• Operating Temperature: -5℃~50℃ (23℉~122℉) • Storage Temperature: -40℃~70℃ (-40℉~158℉) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
